	BST30	BST50
	Washer-Extractor	Tumble Dryer	Washer-Extractor	Tumble Dryer
Control Option	Touch/Key	Touch/Key
Capacity-Ib(kg)	30(14)X2	50(23)X2
Overall Width-in(mm)	31.4(797)	34.4(875)
Overall Depth-in(mm)	45.5(1157)	51.1(1299)
Overall Height-in(mm)	79.8(2027)	84.3(2141)
Cylinder Diameter-in(mm)	24.0(610)	30.0(762)	26.3(668)	33.0(838)
Cylinder Depth-in(mm)	16.0(406)	26.0(660)	20.3(515)	30.0(762)
Cylinder Volume-cu.ft (liters)	4.2(119)	10.6(300)	6.3(178)	14.8(419)
Reversing Cylinder	-	Standard	-	Standard
Door Opening Size-in(mm)	14.3(363)	22.6(574)	16.3(414)	26.9(683)
Door Bottom to Floor-in(mm)	14.0(356)	51.3(1303)	14.6(370)	52.3(1328)
Water Inlet Connection-in(mm)	2x0.75(19)	-	2x0.75(19)	-
Drain Diameter-in(mm)	1x3(76)	-	1x3(76)	-
Drain Heightto Floor-in(mm)	4.3(108)	-	4.3(115)	-
Heat Input Power Btu/hr(kW) Full type Save type	- -	73,000(21.4) 30,712(9)	- -	95,000(27.8) -
Gas Connection-in	-	1/2 NPT	-	1/2 NPT
Air Outlet-in(mm)	-	8.0(200) Elliptical	-	10.0(250) Elliptical
Airflow-cfm(/sec)	-	400(190)	-	600(285)
Motor-HP(kW) Fans Drive	- 2(1.5)	0.5(0.4) 0.3(0.2)	- 2(1.5)	0.5(0.4) 0.5(0.4)
Cylinder Speeds-RPM (G-Force) Wash medium Ultra High	48(0.8) 542(100) 766(200)	- - -	46(0.8) 518(100) 733(200)	- - -
Shipping Dimensions Approx,-in(mm) Width Depth Height	34.5(876) 47.0(1194) 83.0(2108）	35.5(902) 54.0(1372) 89.0(2261)
Net Weight- Ib(kg))	770(349)	910(413)
Shipping Weight-lb (kg)	787(357)	930(422)

BST30

BST50

Washer-Extractor

Tumble Dryer

Washer-Extractor

Tumble Dryer

Control Option

Touch/Key

Capacity-Ib(kg)

30(14)X2

50(23)X2

Overall Width-in(mm)

31.4(797)

34.4(875)

Overall Depth-in(mm)

45.5(1157)

51.1(1299)

Overall Height-in(mm)

79.8(2027)

84.3(2141)

Cylinder Diameter-in(mm)

24.0(610)

30.0(762)

26.3(668)

33.0(838)

Cylinder Depth-in(mm)

16.0(406)

26.0(660)

20.3(515)

30.0(762)

Cylinder Volume-cu.ft (liters)

4.2(119)

10.6(300)

6.3(178)

14.8(419)

Reversing Cylinder

Standard

Door Opening Size-in(mm)

14.3(363)

22.6(574)

16.3(414)

26.9(683)

Door Bottom to Floor-in(mm)

14.0(356)

51.3(1303)

14.6(370)

52.3(1328)

Water Inlet Connection-in(mm)

2x0.75(19)

Drain Diameter-in(mm)

1x3(76)

Drain Heightto Floor-in(mm)

4.3(108)

4.3(115)

Heat Input Power
Btu/hr(kW)
Full type
Save type

-
-

73,000(21.4)
30,712(9)

-
-

95,000(27.8)
-

Gas Connection-in

1/2 NPT

Air Outlet-in(mm)

8.0(200) Elliptical

10.0(250) Elliptical

Airflow-cfm(/sec)

400(190)

600(285)

Motor-HP(kW)
Fans
Drive

-
2(1.5)

0.5(0.4)
0.3(0.2)

-
2(1.5)

0.5(0.4)
0.5(0.4)

Cylinder Speeds-RPM
(G-Force)
Wash
medium
Ultra High

48(0.8)
542(100)
766(200)

-
-
-

46(0.8)
518(100)
733(200)

-
-
-

Shipping Dimensions
Approx,-in(mm)
Width
Depth
Height

34.5(876)
47.0(1194)
83.0(2108）

35.5(902)
54.0(1372)
89.0(2261)

Net Weight- Ib(kg))

770(349)

910(413)

Shipping Weight-lb (kg)

787(357)

930(422)

BCT Hard mount washer advantages

STPP (SP) series washing machine

MH series wet cleaning machine

BST Stacked washer-extractor/tumble dryers advantages

STPP series is dried and washed

STS series is dried and washed

Suspension industrial washer

Fully automatic inclined discharge washer

Hygienic isolated washing machine

STPP (DP) series

BT tumble dryer

BTT stacked tumble dryer

DE dryer

BST Stacked washer-extractor/tumble dryers advantages

STPP series is dried and washed

Suspension distillation type multi-solvent dry cleaning machine

Filter-type multi-solvent dry cleaning machine

Four series of fully enclosed perchloroethylene dry cleaning machine

DS-100 Multi-solvent Distillation Machine

Manual (bagging ) packaging machine

Semi-automatic (bagging ) packaging machine

Steel belt type X-type interactive conveyor line

Steel belt type Z-type interactive conveyor line

Suction blast bridge ironing table

YTT Ordinary Suction Ironing Table (Pedal Type)

22D-1 shoe washing machine

Shoe quick-drying machine (cylindrical 50 pairs)

Ironing machine for tops and trousers

Washing universal boiler press(B-A1-YTJ)

BST Stacked washer-extractor/tumble dryers advantages

(30/50 lb)

Product Overview

Application Industry

Technical features

Elegant appearance

DDerived from European and American design traditions,it boasts an aesthetically pleasing appearance, superior material selection,and meticulous craftsmanship.

Stable

Heavy-duty structure design,utilizing imported components from Europe and America for enhanced quality and eliminating maintenance concerns.

Durable

The selection of components is designed for enhanced durability,boasting a lifespan of 20 years or 200,000 cycles,thereby extending the profit cycle for our customers.

Energy saving

Reduce water usage by 10%.With more advanced motor design and variable frequency drive technology,we achieve a 50%electricity savings every cycle.

More energy-efficient

Axial airflow guidance technology,3D hot air surround,ensuring full contact of hot air with clothing.With a bidirectional frequency conversion structure,it offers both forward and reverse rotations,ensuring clothes don't get tangled,and drying is significantly faster.Elegant appearance

Stable

Heavy-duty structure design,utilizing imported components from Europe and America for enhanced quality and eliminating maintenance concerns.

Durable

The selection of components is designed for enhanced durability,boasting a lifespan of 20 years or 200,000 cycles,thereby extending the profit cycle for our customers.

Energy saving

Reduce water usage by 10%.With more advanced motor design and variable frequency drive technology,we achieve a 50%electricity savings every cycle.

More energy-efficient

Axial airflow guidance technology,3D hot air surround,ensuring full contact of hot air with clothing.With a bidirectional frequency conversion structure,it offers both forward and reverse rotations,ensuring clothes don't get tangled,and drying is significantly faster.

Technical Parameters

High cleanliness

Low breakage rate

Energy-efficient and efficient

Good stability
