volume
Laundry capacity(kg)	10-12	16-18
Drum dissolution (L)	200	320
Drum Diameter(mm)	800	900
Drum depth	400	500

volume

Laundry capacity(kg)

10-12

16-18

Drum dissolution (L)

200

320

Drum Diameter(mm)

800

900

Drum depth

400

500

velocity
Washing speed (r/min)	34	34
Spinning speed(r/min)	370	370

velocity

Washing speed (r/min)

Spinning speed(r/min)

370

Base box capacity
One box (L)	112	164
Two boxes (L)	127	177
Three boxes (L)	112	180
Distillation chamber volume (L)	150	250

Base box capacity

One box (L)

112

164

Two boxes (L)

127

177

Three boxes (L)

112

180

Distillation chamber volume (L)

150

250

power
Total power of machine motor(kw)	5.75	8.05
Drying electric heating power(kw)	4.05	5.4
Distillation electric heating power (kw)	6	6
Water consumption (max.) (kg/h)	500	600
Steam Consumption (Max) (kg/h)	32	42

power

Total power of machine motor(kw)

5.75

8.05

Drying electric heating power(kw)

4.05

5.4

Distillation electric heating power (kw)

Water consumption (max.) (kg/h)

500

600

Steam Consumption (Max) (kg/h)

size
WidthDepthHeight(mm)	170013002100	200715002340
Packing Weight(kg)	1200	1600

size

Width*Depth*Height(mm)

1700*1300*2100

2007*1500*2340

Packing Weight(kg)

1200

1600

BCT Hard mount washer advantages

STPP (SP) series washing machine

MH series wet cleaning machine

BST Stacked washer-extractor/tumble dryers advantages

STPP series is dried and washed

STS series is dried and washed

Suspension industrial washer

Fully automatic inclined discharge washer

Hygienic isolated washing machine

STPP (DP) series

BT tumble dryer

BTT stacked tumble dryer

DE dryer

BST Stacked washer-extractor/tumble dryers advantages

STPP series is dried and washed

Suspension distillation type multi-solvent dry cleaning machine

Filter-type multi-solvent dry cleaning machine

Four series of fully enclosed perchloroethylene dry cleaning machine

DS-100 Multi-solvent Distillation Machine

Manual (bagging ) packaging machine

Semi-automatic (bagging ) packaging machine

Steel belt type X-type interactive conveyor line

Steel belt type Z-type interactive conveyor line

Suction blast bridge ironing table

YTT Ordinary Suction Ironing Table (Pedal Type)

22D-1 shoe washing machine

Shoe quick-drying machine (cylindrical 50 pairs)

Ironing machine for tops and trousers

Washing universal boiler press(B-A1-YTJ)

Four series of fully enclosed perchloroethylene dry cleaning machine

(12/18 kg)

Product Overview

Application Industry

Technical features

All stainless steel construction, carbon steel painted panels

Three-solvent tank design

Heating method: steam heating or electric heating

The TC4200 comes standard with a single centrifugal filtration system

The TC4320 comes standard with a dual filtration system

Touch screen KH234M computer control; Multi-point temperature and pressure automatic protection

World famous brand electrical control components

Air channel shut-off valve, activated carbon adsorption environmental protection recovery device

Refrigeration recovery coil, heat pump energy-saving system

Equipped with leak-proof chassis, safe and environmentally friendly

All doors are fitted with normally closed latches. The door lock closes automatically when shut down or malfunctioning

All manual drain valves should automatically return to their positions and close when the manual has been removed

Complies with national standard: GB25116-2010/ISO 8230:1997

Technical Parameters

High cleanliness

Low breakage rate

Energy-efficient and efficient

Good stability
