volume
Laundry capacity(kg)	8-10
Drum dissolution (L)	200
Drum Diameter(mm)	670
Drum depth	475

volume

Laundry capacity(kg)

8-10

Drum dissolution (L)

200

Drum Diameter(mm)

670

Drum depth

475

velocity
Washing speed (r/min)	40
Spinning speed(r/min)	700

velocity

Washing speed (r/min)

Spinning speed(r/min)

700

Base box capacity
One box (L)	85
Two boxes (L)	85
Three boxes (L)	85

Base box capacity

One box (L)

Two boxes (L)

Three boxes (L)

power
Total power of machine motor(kw)	5.05
Compressor power(kw)	2.6
Water consumption (max.) (kg/h)	250
Steam Generator (kw)	10.5

power

Total power of machine motor(kw)

5.05

Compressor power(kw)

2.6

Water consumption (max.) (kg/h)

250

Steam Generator (kw)

10.5

size
WidthDepthHeight(mm)	162013501960
Packing Weight(kg)	1000

size

Width*Depth*Height(mm)

1620*1350*1960

Packing Weight(kg)

1000

BCT Hard mount washer advantages

STPP (SP) series washing machine

MH series wet cleaning machine

BST Stacked washer-extractor/tumble dryers advantages

STPP series is dried and washed

STS series is dried and washed

Suspension industrial washer

Fully automatic inclined discharge washer

Hygienic isolated washing machine

STPP (DP) series

BT tumble dryer

BTT stacked tumble dryer

DE dryer

BST Stacked washer-extractor/tumble dryers advantages

STPP series is dried and washed

Suspension distillation type multi-solvent dry cleaning machine

Filter-type multi-solvent dry cleaning machine

Four series of fully enclosed perchloroethylene dry cleaning machine

DS-100 Multi-solvent Distillation Machine

Manual (bagging ) packaging machine

Semi-automatic (bagging ) packaging machine

Steel belt type X-type interactive conveyor line

Steel belt type Z-type interactive conveyor line

Suction blast bridge ironing table

YTT Ordinary Suction Ironing Table (Pedal Type)

22D-1 shoe washing machine

Shoe quick-drying machine (cylindrical 50 pairs)

Ironing machine for tops and trousers

Washing universal boiler press(B-A1-YTJ)

Suspension distillation type multi-solvent dry cleaning machine

Product Overview

Application Industry

Technical features

Stainless steel construction, carbon steel painted panels

Three-solvent tank design

Suspension design, 700 rpm.

PLC fully automatic control system, which can be interchanged with automatic and manual operation

Multi-point temperature and pressure automatic protection

Vacuum distillation system

Filtration system

Dark and light colors each have a set of filtration systems

World famous brand electrical control components

World famous brand refrigeration components; Imported bearings

Multiple safety protection devices: safety valve protection, distillation vacuum (negative pressure) protection

The applicable solvents are: hydrocarbon solvents with flash points higher than 60°C, or modified alcohol laundry solvents

Comes with a steam generator

With leak-proof chassis, environmental protection and hygiene

Technical Parameters

High cleanliness

Low breakage rate

Energy-efficient and efficient

Good stability
